Lighting towers

ARISLUX-TRFLED lighting towers on trailers with fixed or variable height rudder and independently powered by great range silenced generators. The lighting system is composed of LED lights. ARISLUX-TRLED lighting towers installed on a light alloy mast with led lights, powered by cigarette lighter socket from a support vehicle.

AZ-FLF60/81ASP aisp

AZ-FLF60/81ASP, Airport Fire Fighting Vehicle, 6 × 6 set on a MAN chassis, 3-axis and meeting ICAO regulations.
Cabin, 2 + 1 seats with controls for use of all equipment.
The body is fastened to the basic vehicle chassis thru a subframe with elastic fasteners and is provided with perimeter lighting, 2 additional Xenon beacons and warning and visual devices (two-tone siren, flashing beacons, strobe).

The body is made of patented Aluminium Panel System – super strength triple anodized honeycomb construction side wall ring panels – with well-lighted compartments 6 for equipment and 1 for pump unit; locked with aluminum rolling shutters while the lower compartments are locked with folding platforms to facilitate access to the equipment positioned at the top.
Main items:

water system with ZIEGLER pump consisting of:
- switch-off system control panel
- centrifugal pump from 6000 l / min @ 10 bar
- centrifugal high-pressure pump 400 l / min @ 40 bar
- fiberglass water tank 8100 l
ZIEGLER foam system including:
- automatic electronic dosing device (constant adjustable from 1 ÷ 6%) for a flow rate from 400 to 6000 l / min
- pre-mixer operated with water from the pump
- high-pressure pre-mixer flow rate 105 l / min @ 40 bar
- fiberglass foam tank built in water tank and divided into two compartments: 510 l in total
Minimax powder demountable system with maximum working pressure 13 bar made of:
- pressure tank 250 kg of Class BC dry powder
- pressurization system with 1 nitrogen cylinder 25 l @ 200 bar
- powder hose reel, 50 m, and nozzle 2.5 kg / s
vehicle protection system made of 3 front nozzles and 2 rear fan nozzles
monitor combined with baffle, 5000 l / min @ 10 bar
5000 l / min approx. 75 m for water and approx. 65 m for foam
front monitor with American type nozzle 1000 l / min @ 10 bar
1000 l/ min approx. 40 m, approx. 30 m for water and foam
2 high pressure hose reels:
- length 80 m with electric rewind
- adjustable flow high-pressure nozzle 40, 80, 130 l / min @ 40 bar.

Airport systems

ARIS designs and manufactures vehicles and special equipment for rescue operations in airport areas: ARISFIRE-BPRP to maintain system efficiency of the multi-purpose powder extinguishing systems on airport firefighting vehicles.

ARISSKY truck

ARISSKY on truck: articulated aerial platforms, fully hydraulic with double pantograph, installed on chassis of light trucks. ARISSKY on truck have compact dimensions and are approved for driving with a B license.
Features:

maximum working height 20 m
maximum working radius 8.5 m
platform rotation 350 °
basket dimensions 1400 mm x 700 mm x 1180 mm h
basket rotation 60 ° right + 60 ° left
maximum basket capacity 200 kg
weight 3340 kg
GVW 3500 kg.

ARISATL on road trailer

ARISATL MPR, off-road vehicle, draining flooded areas. The systems are set up are on approved trailers, 1- or 2-axis, with a fixed or variable height rudder.
Main features:

self-priming motor pump unit on a stretcher or fixed with:
- 4-stroke petrol or diesel engine, electric starter and pull
- centrifugal pump up to 329 m³/h
suction filters
PVC flexible hose with steel spiral for suction with ball joints
hose for drainage.

ARISATL on off-road trailer

ARISATL-MPR, off-road vehicle, draining flooded areas, installed on a 1 axis off-road trailer, approved for road use, with height adjustable rudder. Main features:

trailer
- towing rudder, height from 690 ÷ 1060 mm (empty)
- interchangeable eye
- parking system consisting of
  - foldable small wheel
  - 2 rear telescopic jacks
- tires 7.50 R16 M+S
- capacity 1460 kg
- GVW 2000 kg
soundproof diesel motor pump
- discharge capacity from 329 to 420 m³/h
- maximum head approx. 22 m
- passing solids approx. 75 mm
- maximum pressure 4.8 bar
- suction mouth diameter and delivery 150 mm
- range approx. 40 h
4 suction hoses, jointed 152 mm x 2 m
1 siphon DN150 with “F” ball fitting
1 connection bend 90° DN 150
3 led spotlights on pneumatic telescopic mast
1 rear led spotlight.

Accessories:
Flattened discharge hoses, jointed 152 mm x 25 m stored in galvanized steel cases.

Emptying systems

Special trolleys

ARIS designs and manufactures special trolleys for specific uses.
ARISMOV are used for the handling of fire fighting modules, flooded areas draining modules, T-shaped modules and cargo box modules. ARISRAIL and ARISTUBE trolleys used for railway or subway rescue operations. CR-ISO20 trolleys can handle ISO 20 ft container.

ARISFIRE-ATL pick up

ARISFIRE-ATL: vehicle equipped with a module for emptying of flooded rooms and areas.
The module was designed and manufactured to be easily roll-off and installed in the back of off-road vehicles such as ARISFIRE AIB550 as alternative to AIB550 modules, thus making the vehicle suitable for use in floods.
Key features:

body in the cabin with aluminum locking shutters
5.5 kW gasoline generator with 2 EEC sockets
self-priming diesel pump for dirty water on a stretcher with:
- 4-stroke engine, gasoline-powered, electric start and pull
- centrifugal pump up to 1500 l / min
submersible pump 440 l / min
submersible pump 680 l / min
reels
suction hose with steel spiral
drainage hose
chainsaw
nozzle for street cleaning
traffic cones.
