Category Archives: Sistemi di svuotamento

ARISATL on road trailer

ARISATL MPR, off-road vehicle, draining flooded areas. The systems are set up are on approved trailers, 1- or 2-axis, with a fixed or variable height rudder.
Main features:

  •  self-priming motor pump unit on a stretcher or fixed with:
    • 4-stroke petrol or diesel engine, electric starter and pull
    • centrifugal pump up to 329 m3/h
  •  suction filters
  • PVC flexible hose with steel spiral for suction with ball joints
  • hose for drainage.

ARISATL on off-road trailer

ARISATL-MPR, off-road vehicle, draining flooded areas, installed on a 1 axis off-road trailer, approved for road use, with height adjustable rudder. Main features:

  • trailer
    • towing rudder, height from 690 ÷ 1060 mm (empty)
    • interchangeable eye
    • parking system consisting of
      • foldable small wheel
      • 2 rear telescopic jacks
    • tires 7.50 R16 M+S
    • capacity 1460 kg
    • GVW 2000 kg
  • soundproof diesel motor pump
    • discharge capacity from 329 to 420 m³/h
    • maximum head approx. 22 m
    • passing solids approx. 75 mm
    • maximum pressure 4.8 bar
    • suction mouth diameter and delivery 150 mm
    • range approx. 40 h
  • 4 suction hoses, jointed 152 mm x 2 m
  • 1 siphon DN150 with “F” ball fitting
  • 1 connection bend 90° DN 150
  • 3 led spotlights on pneumatic telescopic mast
  • 1 rear led spotlight.

Accessories:
Flattened discharge hoses, jointed 152 mm x 25 m stored in galvanized steel cases.
download5

ARISFIRE-ATL pick up

ARISFIRE-ATL: vehicle equipped with a module for emptying of flooded rooms and areas.
The module was designed and manufactured to be easily roll-off and installed in the back of off-road vehicles such as ARISFIRE AIB550 as alternative to AIB550 modules, thus making the vehicle suitable for use in floods.
Key features:

  • body in the cabin with aluminum locking shutters
  • 5.5 kW gasoline generator with 2 EEC sockets
  • self-priming diesel pump for dirty water on a stretcher with:
    • 4-stroke engine, gasoline-powered, electric start and pull
    • centrifugal pump up to 1500 l / min
  • submersible pump 440 l / min
  • submersible pump 680 l / min
  • reels
  • suction hose with steel spiral
  • drainage hose
  • chainsaw
  • nozzle for street cleaning
  • traffic cones.
    download5

ARISFIRE-MSV modul

ARISFIRE MSV: modules equipped for emptying of flooded rooms and areas, designed and manufactured to be easily installed in the back of off-road vehicles and make them suitable for rescue operations.
Key Features:

  • AISI 304 stainless steel frame
  • self-priming diesel pump for dirty water on a stretcher with:
    • 4-stroke engine, powered by petrol or diesel, electric start and pull
    • centrifugal pump up to 90 m3 / h
  • self-priming diesel pump for dirty water on a stretcher with:
    • 4-stroke engine, powered by petrol or diesel, electric start and pull
    • centrifugal pump up to 36 m3 / h
  • suction filters
  • PVC hose with steel spiral for suction with spherical fittings
  • drainage hose.
